Two Space Rack Space
6 Mono Mic/Line Input Channels
2 Multi-Input Stereo Line Inputs
Stereo USB Digital In/Out
Variable High Pass Filters on all mono input channels
Designed for use in Mono, Stereo, and LCR applications
Live Performance contracting mixers designed to operate in Mono, Stereo, or LCR applications.
6 Channels of Burr-Brown Microphone Pre-Amplifiers and 2 stereo line input channels with selectable inputs.
Balanced Left, Right, Center and Aux XLR outputs and dual Sum mono outputs use THAT Corporation Out-Smarts balanced output devices.
Individual Solo and Channel On switches on each mono and stereo input channel.
Each input channel is assignable to Left-Right OR Center mix bus.
Mono input channels have High and Low Frequency EQ with variable (20Hz-200Hz) High Pass Filter.
Stereo input channels have High and Low Frequency EQ with fixed High-Pass Filter.
Individual Left, Right, Center and Aux Output Metering with LIMITER active LED indicators.
Mono input channel use Neutrik XLR/1/4” combo connectors and TRS insert and Direct Output connectors.
Stereo input use individual 1/4” balanced left and right input connectors, RCA Inputs and (Stereo Input Channel 1) USB Digital or (Stereo Input Channel 2) front panel stereo input 1/8” connector.
Low phase-shift, wide bandwidth electronic design derived from APB’s Spectra and ProDesk™ products.
